DECIMATOR DESIGN PRODUCT CATALOGUE

SPECIFICATIONS

SDI FORMATS 3G:SMPTE [email protected] and 2.967Gb/s

• 1080p@60/59.94/50Hz

HD:SMPTE 292M/274M/[email protected] and 1.435Gb/s

• 1080i@60/59.94/50Hz

• 1080p/psf@30/29.97/25/24/23.98Hz

• 720p@60/59.94/50/30/29.97/25/24/23.98Hz

SD:SMPTE 259M@270Mb/s

• 625i50

• 525i59.94

LCD / BUTTON

MENU OPTIONS

• Status for all 4 inputs

• HDMI output type and source selecon from SDI inputs 1 to 4

• Quad-Split output format selecon

• Output aspect and type of 16:9 or 4:3 at either 90 or 100% of

screen size

• Quad-split individual aspect format for each input of Same as

output, Leer-box or Pillar-box

• Quad-split Border Enable

• Quad-split mode reference of either Free-run or inputs 1 to 4

INPUTS • 4 x (3G/HD/SD)-SDI 10-bit

• Condional Maximum Equalizaon cable length of 400M

for SDI, 200M for HD-SDI and 100M 3G-SDI using Belden

1694A

OUTPUTS • 4 x mini HDMI Type C

POWER • +5V to +32V DC

• Posive Centre Pin

DIMENSIONS 79.5mm x 123mm x 29.5mm (3.1” x 4.8” x 1.2”)

• Includes 4 independent mini HDMI outputs that can

each output any of the four (3G/HD/SD)-SDI inputs

or a Quad-Split of all them.

For example you could use the unit to have:

- 4 independent SDI to HDMI converters

- 3 independent SDI to HDMI converters with a

quad-split output

- 2 independent SDI to 2 x HDMI converters with

loop through

- A single SDI or Quad-Splt to 4 x HDMI outputs

• Inputs 2 and 4 can be individually changed to output

acve loop copies of inputs 1 and 2 respecvely.

• Quad-Split mode allows selecon of audio from any

input.

• The DMON-4S is a truly portable converter, that

incorporates our new easy to use LCD and buon

control system. This gives you easy access to all of

the amazing features without using complicated

LED/buon control, dip switches or having

to carry around a computer to change a simple

seng.

• This unit also includes:

- USB port for control and rmware updates

- Heavy duty box

- Metal Thread Locking DC Power Socket

- Power Supply, HDMI Cable and USB Cable

PRODUCT FEATURES

DMON-4S: Quad (3G/HD/SD)-SDI to HDMI Mulviewer and Converter

DMON-4S

Quad (3G/HD/SD)-SDI

to HDMI Converter

and Mulviewer
